Animated Fire


Disclaimer: Please note that this tutorial requires the use of a filter only present in Photoshop CS (or later). If you don't have a modern version of Photoshop, you may have to improvise a little, or find a custom plugin to get a similar effect.

Ever since we first learned how to make it in the stone age, mankind has had a profound fascination with fire.  Directly or indirectly it warms our houses, cooks our food, and lights our footpaths at night.  Now you too can set Photoshop ablaze with the power and beauty of fire by following this animated 9 step tutorial.  Just remember to play safely, and not singe your fingers!

Step 1: Create a new document of any size, but try to begin with a canvas slightly larger than you actually need. For example: if you need a fire of 200 by 200px, start off with a 300 by 300px canvas.

Lets get started.  Set your foreground to #414141 and background to a solid white (#FFFFFF). Then select Filter > Render > Clouds from the main menu. Now go to Filter > Render > Fibers and enter these settings:

Variance: 17.0, Strength: 4.0

You should end up with an image that resembles the one on the left.

Step 2: Now duplicate this layer,  reselect your original layer and press 'CTRL+U'. Tick colorize and enter these settings:

Hue: 0, Saturation: +80, Lightness: +10

And for the duplicated layer we do the same, but with these settings:

Hue: +50, Saturation: +90, Lightness: 0

Duplicate the yellow layer and set its layer blending mode to Linear Burn.  Reselect the original yellow layer and change its blending mode to lighten at 70% opacity. Flatten/Merge all layers.

Step 3:  Run Filter > Distort > Shear with the settings shown on the left (but don't be afraid to play with these settings a little). Then apply a motion blur with the angle set to 90 and the distance set to 15px.

Step 4: Now we can start preparing the fire for animation. Drag a horizontal guide to the exact centre of your canvas and select the top half of your canvas. Right-click on your layer in the layer palette and choose 'Layer via cut'. Drag the top half of your image to the bottom and the bottom half to the top. It should look like the image on the left.

Step 5: Here comes the difficult part of the tutorial that requires some judgement from your side. We are gonna try to blend the two halves into each other. There are several ways to do this, so pick the one that works best for you.  This is the method I used:

First, grab your Eraser Tool and change the setting to a Soft Brush about 100px in size. Then position the brush in a similar position to the example on the left. As you see, I went on and erased a part of my bottom half and I have positioned my eraser to do the top half. Just press and hold shift to erase a nice straight line. Pass your eraser about four times over the entire width of the canvas.

Step 6: After you finished smoothing the edges, nudge up the bottom half upwards until you no longer notice the transition from the top half to the bottom half (if you followed my instructions carefully, this should be 50px upwards).    As you can now plainly see, the image is a little smaller than the one we started using in step 1, and that's why I recommended you started with a larger canvas than you initially needed.

It should now resemble the image opposite.

Step 7: Now just merge the two layers, CTRL+click the layer in the layer palette, and Image > Crop.

Duplicate this layer and position it directly below the the other one so that it is off your canvas. See the image on the left for a quick animated explanation.

Step 8: Now on to the animation. Press 'CTRL+SHIFT+M' to switch to ImageReady(IR). Once in IR make sure your two layers are still linked. Take a look at your animation palette (if it's not open, click on Window > Animation) and add a new frame at the end. Select the last frame and drag your layers up till one of the layers disappears from your canvas and the other shows up. Then select both frames in your animation palette and click the 'Tween' icon. Add 15 frames and click OK. We're almost finished...   Now just remove the last frame and you have a seamless looping fire effect.

Step 9: Well, that's it for the fire! Feel free to add a layer on top with a few transparent areas if you want a cool flaming text effect.   I hope you learned a lot from this tutorial and now know how create your own animated fire effects. For a little fun, experiment with different colours and speeds for the fire. If you have any questions just register at the forums and post them there. I'm sure that a lot of guys (and gals) can help you with your problems.

- Tutorial written by Malboroman

Automatic Translations: Translate Into French Translate Into German Translate Into Italian Translate Into Spanish Translate Into Portuguese

Last 5 User Comments

User:  Dr.Del (#58086)
Date: Tue Jan 26, 2010. 20:04:14

Post #21 of 21

Does anyone know how to inbed the flames inside the text as in step 9?

Reply to this post


User:  closeupman (#53885)
Date: Tue Oct 14, 2008. 20:39:45

Post #20 of 21

------------
Step 7: Now just merge the two layers, CTRL+click the layer in the layer palette, and Image > Crop.

Duplicate this layer and position it directly below the the other one so that it is off your canvas. See the image on the left for a quick animated explanation.
---------------

You should add:
Then position the original one so they appear seamless(as one).
Now...VERY IMPORTANT!!!
LINK the layers (not sure if it's the same in all PS versions....but in CS2...you select the layers...right click...and select link layers...both layers must be regular layers(i.e. one can't be a background layer))

THEN drag 'em down until you see transparency, then drag back up so the top of the layers is at the top of the canvas(i.e. no transparency showing).

You can see this in your animation, but it is such a small window, that it is easy to miss this operation!

As to the drag one until it disappers...I have NO idea...an animation might have helped here.

I just dragged until it seemed like the other layer appeared(i.e. they didn't seem as one)...I even dragged till I saw some transparency and then deleted these extra frames...

As to the looping... After deleting my extra transparency appearing frames...I deleted the last frame and it WORKED!!! :Overhere:

Check out my attachment.


ArtWanted.com | David FRIEDMAN | Artwork Portfolio

Reply to this post


User:  Nintendo_Ownes7 (#52707)
Date: Thu Sep 11, 2008. 15:29:33

Post #19 of 21

I got it to animate but when I made it a gif it didn't work. I was a little confused animating it but I got it to work it just wouldn't show up when I made it a gif.

Is their a difference with gifs if I was on a Mac? I made it on a Mac but it wouldn't work on my PC.

Reply to this post


User:  Kathleen (#49190)
Date: Sat Apr 05, 2008. 16:00:09

Post #18 of 21

:confused:
Using CS2, I found "layer via cut" only if I right click on the selection not the layers palette. Is that something new in CS3?
I'm not new to Photoshop, but I'm having a hard time with the animation - as soon as I put it in Image Ready, one of the layers becomes blank.
So that's only how far I can go.............I tried using the Photoshop animation instead, but it goes wavy (back and forth) instead of up and down.......help?
Thanks!
BTW - yours looks gorgeous - I want to do this!!!!!:help:

Reply to this post


User:  cinimodaz (#40228)
Date: Wed Apr 04, 2007. 18:55:30

Post #17 of 21

I make the flame just fine steps 1,2,3 but then from 4 on it gets to confusing for me. I was able to make it animate somewhat but it is jumpy it goes through a flame animation then resets to the original position making it look like it is just a loop not a on going transition. What am I doing wrong?

Reply to this post
